DC DC Konvertör - 1000
watt - 500 watt - 350 watt - 200 watt - 150 watt - 100 watt |
|
DC/DC
Konvertörler
|
|
|
| Meanwell |
DC/DC
Converters | |
|
FEATURES
Designed to meet telecom std ETS 300-132-2
Up to four regulated outputs
Independent short c. prot. for each output
Output overvoltage protection
EMC : EN55022 Class A
Teknik özellikler için mutlaka ürün pdflerini
isteyiniz...
|
Ürün fotoğraflarını ve pdflerini
isteyiniz... |
|
|
Teknik Özellikler |
|
MODEL |
GÜÇ |
GİRİŞ |
ÇIKIŞ Voltajı |
ÇIKIŞ Akımı |
FİYATI |
ÜRÜN LİNKİ |
|
|
|
|
|
|
SD-500L |
500 Watt |
19-72 Vdc |
12 |
0-40 A |
239.-USD |
SORUNUZ |
|
24 |
0-21 A |
239.-USD |
SORUNUZ |
| 48 |
0-10,5 A |
239.-USD |
SORUNUZ |
|
72-144 VDC |
12 |
0-40 A |
239.-USD |
SORUNUZ |
| 24 |
0-21 A |
239.-USD |
SORUNUZ |
| 48 |
0-10,5 A |
239.-USD |
SORUNUZ |
|
|
|
|
Standard
Specification :
| Input undervoltage |
Vin < 46V ±2V for model 01
;
Vin < 33V ±2V for model 02, 03 |
Options : |
| Short circuit
protection |
Constant current on each
output |
- Plastic case material
- Black zinc finish metal case
- Short circuit and maximum output current
customization available on output Vo1 up to 3,5 A and up to 4,5 A
on Vo3 with power output max 30W
- Turn on delay time up to 200 ms
- Turn on delay time down to 5 ms
- Isolation output / case 0 V
- Extended operating temperature -40 °C, +60
°C
|
| Turn-on delay time |
< 150 ms. |
| Turn-on rise time |
< 2 ms. |
| Switching frequency |
280 kHz, ± 10% |
| Dimensions ( W x L x H
) |
3" x 2,4" x 0,52" (
76,3 x 61,1 x 13,3 mm ) |
| Weight |
90 g. |
| Safety |
EN 60950 / IEC 950 |
| EMC |
EN 55022 Class A |
| Isolation |
Input / Output
1500 VDC |
| Input / Case
1500
VDC |
| Output / Case
500 VDC |
| Operating amb.
temperature |
-10 °C, +60 °C |
| Storage temperature |
-40 °C, +90 °C |
| Humudity max. |
95% non-condensing |
| Heat dissipation |
Free air convection cooling with
vertical mount |
| | |
|
|
|
|
|
